Name:GF-B Coating and Laminating Machine
No:GF-B

Performance and Characteristics

This machine is suitable for coating and laminating various packaging materials, such as refrigerant food, dry food, medicine products, commodity, etc.

This machine is our new design machine ,which was developed according to good experience for making laminating machine of many years together with customers' demands . First base material of this machine uses photoelectric automatic tracing error correction for unwinding, magnetic powder tension control, scrapper oven temperature is auto controlled by segments with pneumatic back press moving style, big roller heating by heating gluing laminating with pneumatic control and double frequency converter timing technology, as a result, this machine has the features of high-speed, low noise, light air pollution, low consumption, stability running, etc. It's suitable for laminating aluminum foil, cellophane paper together with polypropylene, polyethylene film, etc. The laminated film has the good features of high hardness, water-proof, air-proof, lipid-proof, refrigerant, etc.

Main Technical Parameters

Model

GF-600B

GF-800B

GF-1000B

Max width of laminating

600mm

800mm

1000mm

Max diameter of material

¢700mm

¢700mm

¢700mm

Number of laminating layer

2 layers

2 layers

2 layers

Speed

10-130m/min

10-130m/min

10-130m/min

Oven temperature

120℃ (Room temperature)

120℃ (Room temperature)

120℃ (Room temperature)

Total power

30.6kw

34.6kw

38.7kw

Weight

4000kg

5000kg

6000kg

Overall dimension(LxWxH)

8770×1180×3190(mm)

8770×1380×3190(mm)

8770×1580×3190(mm)
