Brief Introduce :
Fully Automatic high-speed paper cup machine LBZ-LAB Model was developed on the basis of imported technologies and combination of advanced domestic and foreign technologies.It’s the first creation at home.It can automatic feed paper,weld through ultrasonic wave(binding the cup wall),oil,punch,heat,knurl,roll side,discharge cups,continually process,test through photoelectric cell,alarm upon encountering troubles and count.It is a good equipment to produce double-side PE-coated beverage cups,ice cream cups and coke cups.
Technical Specification
Model: LBZ-LAB
Cup Size 7oz-36oz
Raw Material:Two-side/one side PE(Polyethylene)film coated paper(170-350g/m2)
Productivity:55-75 pcs/min
Power Source 380V 50Hz or other required
Total Power:11 KW
Weight:2100 Kg
Package Size:2850 x 1700 x 1750mm
Finished Products' Usage:
Double sides PE coated paper cups are widely used for all kinds of drinks: hot drinks(hot coffee cups, hot water cups), cold drinks paper cups(ice-cream cups),all kinds of beverage, and some other special use
Paper Cups Samples Show:
Single Side PE Coated Paper Cups
Specification:
Automatic control adopts optically controlled non-contact switch,
Micro-controlled transducer,
Step-less speed adjustment,
Paper Cup-fan-wall body sealed by Ultrasonic System,
Paper Cup bottom sealed by heater.
Full automatic,
Easy changing molds produce different sizes paper cups,
Easy operating by operator (one operator is enough),
Easy maintenance with minimum cost,
Cheap operating cost and low investment,
Amelioration:Air compressor aren't required for this type paper cup machine when the paper weight under 300gsm.
Ruian City Luzhou Machinery Co.,LTD is one of the biggest industrial enterprise in mechanical in Zhejiang Province and specializes in packaging related machinery as : Paper cup machine, Paper bowl machine, Paper bowl over-coating machine,Paper plate machine,Paper dinner box machine,Paper container series forming machinery equipments and packaging related machinery.
With advanced technological equipments, tremendous technical strength, rich manufacturing experience and reliable product quality, our company can develop new products through cooperating with relevant scientific and research units, universities and institutions and provide equipment, technology, raw material and overall for the enterprises engaging in producing various paper products.
Model LBZ-LB Double Coated Paper Cup Machine, Model LBZ-LA Full-automatic Paper Cup Machine and Model LBZ-LC Full-automatic Paper Bowl Machine of \"LUZHOU\" Brand are developed by our company through importing and absorbing advanced technology from home and abroad, Paper both imported from abroad and made domestic would be suitable to these machines (Paper range from 150 gsm to 420 gsm ).These machines can produce various products through easily exchanging the molds and feature the advantage of one machine, multiple products. Besides, our company also manufacture such equipments as LBZ-LD Full-automatic Paper Bowl Shaping Machine, LBZ-LF Full-automatic Paper Bowl Hollow Shaping Machine, LBZ-B Semi-automatic Paper Meal Box Machine, LBZ-C Full-automatic Filling and Sealing Machine, MLCB930 Creasing and Cutting Machine, The environmental equipment protection series machinery equipments produced by our company are popularized by the World Environment Organization for clearing away white pollution and initiating environmental protection
Since company was founded in 1985, productions are made better and better, and has passed the science appraisal and the technology appraisal, ISO9001:2000 International Quality Identification System ,They are judged as Famous and Excellent Extended Production in Zhejiang. Our company will serve customers at home and abroad whole hearted with first-class products, quality, service and best price, and warmly welcome friends of all circles to visit us for business discussion.
