Specification:
1 the machine use frequency changer, PLC etc high quality electric
component. The system is advance, the veneer output is equal.
2 the machine body have heat treatment can make sure the machine body not change shape
3 it is automatic adjust the knife. Suitable for cut all kind diameter log
4 the feed part use nut and screw
5 after shaft use reduction box, reduce the failure rate
6 can cut all kind of wood, especial for hard wood
7 easy operate , not high requirement for operate worker.
model
|
BXQ1815
|
BXQ1822
|
BXQ1827
|
Max.cutting length(mm)
|
1350
|
2000
|
2600
|
Max.cutting diameter(mm)
|
Φ300
|
Φ300
|
Φ300
|
Log-core diameter(mm)
|
Φ26
|
Φ26
|
Φ26
|
Cutting thickness(mm)
|
0.8-3.0
|
0.8-3.0
|
0.8-3.0
|
Veneer output speed(m/min)
|
42
|
42
|
42
|
power(kw)
|
19.75
|
21.75
|
25.75
|
Overall dimensions(mm)
|
3320*1800*1260
|
3700*1800*1490
|
4585*1800*1560
|
Net weight(kg)
|
3500
|
5500
|
7000
|
Qingdao haiyong machinery manufacturing co., ltd with nice location
and great convenience in communications, is located in Jiaozhou, the
manufacturing base of jiaodong peninsula. There are many main roads
across jiaozhou, such as, Jiaoji Railway, Jiaohuang Railway, Jiaoxin
Railway, Jiqing Highway, the Ring Highway of Jiaozhou Bay, Tongsan
National Highway, Qinghong Highway, National Road No.204.
Our company has a distance of 35 kilometers to Qingdao Port, of 30
kilometers to Qianwan Huangdao Port , of 25 kilometers to Liuting
International Airport . Our company is a woodworking machinery
enterprise with 11 years precision mechanical processing. After the
introduction of some key equipments, such as 5 surface processing
center, guideway grinder, Modern Horizontal boring and milling machine,
our company has reached the international advanced level in the
technology of producing the main components of our manufacturing
equipments.
The main products of our company are lengthways veneer slicers, knife
grinding machines,veneer peeling machine, veneer guillotine,cold press
machine, hot press machine. We have processied and produce the
woodworking machine for many company in qingdao,linyi,guangxi. In the
year 2012, we chaneg the bussiness type, and build our own
company-qingdao haiyong machinery manufacturing co .,ltd. In order to
make our products operate more easily, we have adopted the touch screen
and the PLC microcomputer control procedures of the Germany Siemens. The
easy operating system has uplifted working efficiency for production
and processing. Since the establishment of our company, with strong
professional production technology, excellent woodworking machinery
products, perfect before/after sales service system, reasonable price
and professional accomplishments, we have won many costumers. welcome
and trust.
In the future, we will spear no efforts to develop new products.
