1.
Double-working position disc-type unwinder/rewinder at high stable
performance and the machine has the humanism design; new-type safe chuck
assures the operators safety; unwinding cutter can complete up cutting
or down cutting.
2. Infeed is at precise double-tension control.
3. Low-damping chill roller with good cooling effect prevents the web from being damaged at high- speed machine performance.
4. Centralized lubricant system at dosing greasing makes the guide roller high-speed and flexible performance.
5.
Direct pressing mechanism makes the web performance without distortion,
which can improve register accuracy and reduce the waste.
6. New-type environment protection and energy-saving drying system controls the residual impregnant efficiently.
7. Movable ink tray carriage shortens the auxiliary time and improves the producti vity.
8.
Straight-line cutter makes not only obverse/reverse cutting but also
clearance-rewinding, and the rewinding reel is very tidy.
9. MMI touch screen and vector varispeed control system have the good performances
|
Max web width |
1050/1250/1500㎜ |
|
Print speed |
250m/min、300m/min |
|
Register accuracy |
≤±0.10㎜ |
|
Unwind/rewind dia. |
Ф800㎜ |
|
Plate cylinder dia |
Ф120㎜-Ф300㎜ |
|
Drying method |
electricity heating, steam heating or oil heating(choose freely) |
