Technical Specification:
Thickness: 16-35micron width: 150mm-1860mm
Length: 150m-500m/1 "paper core; 1000m-4000m/3" paper core
Application scope: books, pictures, posters, color printed film on the surface
APPLICATION MANUAL
1. Adjust rollor pressure and temperature according to different types of paper and ink.
2. When using the film for the first time or changing to other thickness, we recommend a small trial volume before going into mass laminating.
3. The following situation will affect the quality of laminating:
A. Using metal ink.
B. The ink contains too much wax, drying oil, anti-adhesive and silicon additive, etc.
C. The ink is too thick.
D. The ink is not completely dry.
E. The humidity of paper is high.
F. Too much powder.
Process parameters
Equipment for lamination film;Dry and wet laminating machine
Temperature:Normal:85℃-110℃
Special:100℃-130℃
Roller Pressure:10-18MPa
Speed:8-50m/min
Process parameters
1.Adjust rollor pressure and temperature according to different types of paper and ink.
2.When using the film for the first time or changing to other thickness,we recommend a small trial volume before going into mass laminating
3.The following situation will affect the quality of laminating
Using metal ink
The ink contains too much wax,drying oil,anti-adhesive and silicon additive,etc
The ink is too thick
The ink is not completely dry
The humidity of paper is high
Too much powder
Taicang E-Ler Packaging Material Co., Ltd. is located in Taicang City, Jiangsu Province, on the north side of Shanghai. 1.5 hours driving from our factory to Shanghai Pudong International Airport. The city is surrounded by fine ports such as Shanghai Port, Yangshan Port and Taicang Port. Traffic is highly convenient.
As one of the leading manufacturers of Thermal Lamination Film in China, we are specialized in production and sales of Thermal Lamination Film. Our annual capacity is over 5000 tons. We produce all kinds of Thermal Lamination Films such as BOPP, PET, Metalized Film, Holographic Film, Digital Film, Soft Touch Film and Anti-scratch Film. The environmental friendly products contain no hazardous substance and are widely used on book covers, magazines, brochures, printed packaging boxes and paper bags, etc. Our products are approved by SGS and other authorized institutions.
Our company highly values the quality of our products. We strictly apply quality control to every procedure of production to ensure quality and stability. Rely on the advanced technology, excellent management, quick responding after-sale services and dedicated workforce, we have exported to more than 20 countries in the Middle East, South-east Asia, South America and Africa while our domestic market share picks up every year.
